Weight | 6 kg, 4.5 kg |
---|---|
Dimensions | 37 × 45 × 25 cm, 103 × 20 × 18 cm |
Accuracy | +/-1.5mm @ 20m |
Battery | Ni-mh Rechargeable Battery, Battery Caddy – C Cell |
Case | Hard Case with Protective Foam |
Extra Features | Tilt Mode, VWS Mode, Scan Mode |
Grade Setting | Single Grade, Manual Grade – Slope Remote |
Grade Range | +/- 8% |
Colour & Laser Class | Red – Class 2 |
Laser Type | Rotating Laser |
Horizontal Levelling | Auto-Levelling – Electronic |
Mounting Options | 5/8" Survey Thread |
Range | 500m Diameter |
Receiver | LR715 – Dual Display Receiver |
Tripod & Staff Included? | Yes |
Warranty | 5 Years |
Instruction PDF can be viewed, printed and downloaded HERE
Range Brochure PDF can be viewed, printed and downloaded HERE
includes Heavy Duty Tripod and 2.4m Staff Bundle (240HDF)
All RedBack Laser Levels have been Checked and Calibrated in Australia and come with a FREE certificate of calibration.RedBack Lasers EL614 range of Electronic Self-Levelling Rotating Laser Levels.
RedBackLasers 2.4K views
Scan Mode with the EL & EGL range of RedBack Lasers
RedBackLasers 956 views
Tilt Function on RedBack Lasers EL614 & EGL624 Range
RedBackLasers 1.8K views
VWS Vibration Wind Sensor Feature RedBack Lasers EL & EGL Models
RedBackLasers 906 views
Setting a Manual Grade RedBack Lasers
RedBackLasers 3K views
Setting an Automatic Grade with RedBack Lasers Grade Match Tracking Lasers
RedBackLasers 2.5K views
RedBack Lasers EL614GM Builders laser with Millimetre and Grade Tracking Receiver
RedBackLasers 5.3K views
RedBack Lasers EL614 Rotating Laser
RedBackLasers 1.1K views
Rotating Grade Laser Package ideally suited for general site levelling drainage and more. Perfect for concreters and general building contractors.
The EL614S is a fully automatic levelling Electronic Rotating Grade Laser with easy to use controls. Simply place laser level on a tripod (optional extra) and press the power button, in seconds it self levels and begins to rotate. The EL614S is extremely tough with steel internal chassis and heavy duty rubberised casing it can handle use day in, day out on the toughest of job sites.
The RedBack EL614S includes remote control and with this can set grades making this laser useful for plumbing and drainage applications.
The EL614S features TILT function in that if this is selected and the laser is disturbed or knocked the beam will stop rotating and indicate something has moved. It also features V W S (vibration and wind setting) when selected the EL614S will continue to spin even when making minor adjustments due to vibrations, without it selected it will stop rotating each time to make those minor adjustments.
The EL614S comes complete with Heavy Duty LR715 electronic receiver with dual LCD displays front and back. The EL614S also comes with rechargeable batteries and charger, but, can also be used with standard “C” batteries or even be powered of the charger/power supply. The included remote control is required for setting a grade.
The EL614S is ideal for concreters and contractors who need a tough, reliable and accurate laser, also ideal for all general site levelling applications and grade setting.
The RedBack EL614S comes with a 5 Year manufacturers warranty.
includes Heavy Duty Tripod and 2.4m Staff Bundle (240HDF)
All RedBack Laser Levels have been Checked and Calibrated in Australia and come with a FREE certificate of calibration.
